WIFI
AIRPLAY 2
BLUETOOTH
SPOTIFY CONNECT
OPTICAL CABLE
UPNP
IMPLOSIVE SOUND
A CLASS OF ITS OWN.
–
A single speaker that changed many things. The laws of physics had spoken: implosive sound simply could not be achieved in wireless form. After more than a decade of research and development and hundreds of patents filed, Phantom I succeeded in shattering limitations. Distinctive and iconoclastic, it packs groundbreaking technologies to deliver an intense listening experience, the kind you feel in your bones and in your soul, for real.
ANATOMICAL ANOMALY.
–
Over 10 years of research and development, 200+ patents filed, and 100 specialists in aerodynamics, automotive, acoustics, and mechanical engineering. That’s all it took to perfect a system capable of pushing the limits of physics, and deliver standard-setting performance. Zero distortion, zero saturation, zero background noise.
ENGINEERING EXCELLENCE.
–
Devialet thrives on end-to-end innovation (hardware, software, design inside and out, manufacturing) to offer ever-enhanced acoustics. In fact, to create Phantom, we have had to build our own plant, hire talents who were used to unique challenges in other industries, conceive our own robotics and quality control. 200+ patents and 90+ awards later, Devialet designed a new breed of speaker.
HIGH-RES
–
Phantom now combines industry-leading sound engineering with more high-resolution capabilities in order to deliver exceptional listening experiences to the many. Along with UPnP and the analog/optical input, Phantom is also Roon Ready, giving all Phantom users ways to enjoy 24-Bit Hi-Res audio like never before.
ANY SOURCE, ONE ARCH.
–
Phantom fans can now take their device even further with Arch. The must-have accessory for music lovers who want to enjoy their audio source without necessarily having it near a speaker, Arch adapts to three different type of sources: Phono, 1 x analog line input, or 2 x S/PDIF (coaxial) digital inputs.
“Highly intuitive and connectable, Phantom I 108db Opera unleashes the physical impact of high-end, ultra-dense sound with more power, clarity, and precision than any other wireless speaker.”
Tech Specs
LOUDSPEAKERS
Grade 1 Titanium Tweeter driver
Aluminum Medium driver
Aluminum Bass drivers
DIGITAL TO ANALOG CONVERTER
Devialet DAC embedded in Devialet intelligence Processor
24bits/96kHz
THD: -112dB
OPERATING SYSTEM
Devialet Operating System 2 (DOS 2) up to 24bits/48kHz
PROCESSOR
ARM Cortex-A9 1.25GHz processor 512MB DDR3-1600 memory
SIDE PLATING
Body: white RAL 9016 | Moongold gilded sides (precious and stainless palladium-yellow gold alloy) | White RAL 9016 dome drivers
MAXIMUM SOUND LEVEL
108 dB SPL at 1 meter
TOTAL AMPLIFICATION POWER
1100 Watts RMS
AMPLIFICATION PERFORMANCE
THD+N* : 0.0005% | Saturation : 0 | Background Noise 0 dB SPL at 50 cm (-15,5 dB SPL at 3m) (*Total Harmonic Distortion + Noise)
FREQUENCY RESPONSE (BANDWIDTH)
Bandwidth : 14Hz to 27kHz (@-6dB)
Accuracy in frequency response : ± 2dB from 20Hz to 20kHz
SYNCHRONISATION
Phantom synchronisation via Wi-Fi, Ethernet or PLC.
CONNECTIVITY
Airplay 2
Spotify Connect
Bluetooth : A2D and AVRCP profiles, AAC, SBC audio codecs
Roon Ready (Inputs up to 24bits/96kHz)
UPnP Renderer (Inputs up to 24bits/96kHz)
Toslink optical input (Inputs up to 24bits/96kHz)
NETWORK
Wi-Fi Dual-band (a/b/g/n/ac 2.4GHz & 5GHz)
Ethernet RJ-45 10/100/1000 Mbps (Gigabit)
CPL Homeplug AV2
APP
Devialet app (iOS, Android)
Weight
11.4 kg
Dimensions
Width: 252 mm | Height: 255 mm | Depth : 342 mm
IEC 100-240V ~ 50/60Hz
Power consumption: 0.5W (in standby)
