S526 HCS Home Cinema System
The S526 HCS Home Cinema System delivers high-quality surround sound and sleek design at an affordable price. Available in black ash or dark apple finishes, all speakers feature soft-feel black baffles for a premium look. The S526 includes optional speaker spikes, while the S522 and S52 CEN have built-in keyhole mounts for wall mounting.


- Type: Passive home cinema speaker set
- Drivers:
- Floor standing: LF: 2 x 165mm (6.5″) woofer, HF: 1 x 25.4mm (1″) positive dome tweeter, ADW (Anti-Diffraction WaveGuide), DTT (Decoupled Tweeter Technology)
- Centre channel: LF: 2 x 102mm (4″) woofer, HF: 1 x 25.4mm (1″) positive dome tweeter, ADW (Anti-Diffraction WaveGuide), DTT (Decoupled Tweeter Technology)
- Surround: LF: 1 x 102mm (4″) woofer, HF: 1 x 25.4mm (1″) positive dome tweeter, ADW (Anti-Diffraction WaveGuide), DTT (Decoupled Tweeter Technology)
- Bandwidth (+/-3dB): Floor standing: 45 Hz – 20 kHz, Centre channel & Surround: 90 Hz – 20 kHz
- Low-frequency Cut-off (-6dB): 42 Hz
- Crossover Frequency: Floor standing: 2300 Hz, Centre channel & Surround: 3000 Hz
- Sensitivity (2.83V @ 1m): Floor standing: 87 dB, Centre channel: 86 dB, Surround: 85 dB
- Power (Rated / Peak): Floor standing: 130 W / 260 W, Centre channel & Surround: 80 W / 160 W
- Recommended Amplifier Power: > 80 W
- Impedance: 6 Ω
- Configuration: Complete 5.0 home cinema speaker system
- Finishes Available: Black ash or dark apple
- Baffle Design: Soft-feel black baffles (all speakers)
- Tweeter Technology: ADW (Anti-Diffraction WaveGuide), DTT (Decoupled Tweeter Technology)
- Mounting Options: Optional speaker spikes (S526), Built-in keyhole mounts (S522 & S52 CEN)
- Dimensions HxWxD: Floor standing: 1000 x 195 x 318 mm, 39.4″ x 7.7″ x 12.52″, Centre channel: 134 x 400 x 210 mm, 5.3″ x 5.7″ x 8.27″, Surround: 240 x 134 x 210 mm, 9.4″ x 5.3″ x 8.27″
- Weight (Packaging Included): 43.5 kg / 33.5 lbs
- Floor standing: Bi-Wiring Terminal
- Centre channel & Surround: Single-Wiring Terminal
- Amplifier Required: Yes (minimum 80W recommended)
- Impedance: 6 Ω (compatible with most amplifiers)
- System Configuration: Passive speakers requiring external amplification
